Tektronix 5A48 Arbitrary Function Generator, AFG Series

Frequency Range:up to 50 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary

Sampling Rate:1 GSa/s

Resolution:14-bit

Output Amplitude:20 Vpp into 50 Ohms

Phase Shift:+/- 1 degree

Interface:USB, LAN, GPIB

Memory Depth:16 kSa

Built-in Functions:FFT, Bode Plot

    The Tektronix 5A48 Arbitrary Waveform Generator is a high-performance instrument designed to meet the demanding requirements of modern electronic systems. Its advanced arbitrary waveform generation capabilities allow users to create complex signals with ease, making it perfect for testing and validation in various industries.

    This model features a wide frequency range from 1 µHz to 50 MHz, enabling it to generate a variety of waveforms including sine, square, triangle, ramp, pulse, and user-defined arbitrary waveforms. With a sampling rate of up to 1 GS/s and a resolution of 14 bits, the 5A48 ensures precise and accurate signal generation.

    The built-in arbitrary memory of 1 Mpts allows for the storage and recall of detailed waveforms, providing flexibility and convenience in the lab or on the production floor. The device also includes multiple interface options such as USB, LAN, and GPIB, ensuring seamless integration with existing test setups.

    Designed with user-friendliness in mind, the Tektronix 5A48 offers intuitive controls and a clear display, allowing for easy setup and operation. Its robust build quality and reliability make it a trusted choice for engineers and researchers working on critical projects.

    Whether you are developing cutting-edge technology or performing routine maintenance, the Tektronix 5A48 Arbitrary Waveform Generator is an indispensable tool for achieving precision and accuracy in your measurements.
