Allen-Bradley 1786-TPYR Thermocouple Input Module

Module Type:Temperature Process Module

Compatibility:Allen Bradley ControlLogix

Input Range:0-1000°C

Resolution:0.1°C

Accuracy:±0.5% of reading ±1°C

Communication Interface:Ethernet/IP, Modbus TCP

Operating Temperature:-40°C to 85°C

Power Supply:24V DC

    The Allen-Bradley 1786-TPYR Thermocouple Input Module is engineered to deliver high precision and reliability in industrial temperature measurement applications. This module supports multiple types of thermocouples, ensuring compatibility with a wide range of temperature sensors. Its robust design, featuring NEMA 4X/IP65 environmental ratings, makes it suitable for use in challenging environments such as factories and outdoor installations. The module offers 8 input channels, allowing users to connect multiple temperature sensors, and provides an accuracy of +/- 0.5% of reading + 1°C, ensuring precise temperature monitoring. With a fast response time of less than 100 ms, the 1786-TPYR ensures real-time data acquisition, making it ideal for process control and automation systems. The module operates on a 24V DC power supply and can communicate via Modbus RTU protocol, offering seamless integration with existing industrial networks. The user-friendly interface simplifies installation and configuration, reducing downtime and maintenance efforts. Whether you’re managing industrial processes or automating manufacturing lines, the Allen-Bradley 1786-TPYR Thermocouple Input Module is a reliable choice for your temperature measurement needs.
