Allen-Bradley 1769SC-IT6I Analog & Thermocouple Input Module

Module Type:Analog Input / Thermocouple Input Module

Model Number:1769SC-IT6I

Manufacturer:Allen-Bradley

Input Channels:6 Channels

Voltage Range:0-10V DC

Current Range:4-20mA

Thermocouple Types:J, K, T, E, R, S, B, N

Resolution:16-bit

Accuracy:+/- 0.1% of reading

Operating Temperature:-25°C to +60°C

Power Requirements:24 VDC

Communication Protocol:RS-485 Modbus RTU

    The Allen-Bradley 1769SC-IT6I module stands out as a versatile solution for industrial applications requiring high precision analog and thermocouple inputs. This module integrates seamlessly with Allen-Bradley’s ControlLogix platform, providing robust connectivity options for diverse sensor setups.

    Crafted with durability in mind, this module is built to withstand harsh industrial environments, ensuring reliable performance over extended periods. Its compact design allows for easy installation in tight spaces, making it ideal for upgrading existing machinery or integrating into new systems.

    Equipped with 6 input channels, the 1769SC-IT6I supports a wide range of voltage and current signals, along with multiple types of thermocouples. This versatility makes it suitable for various industries, including manufacturing, energy, and food processing.

    With its precise resolution of 16 bits, the module ensures accurate data acquisition, contributing to enhanced system performance. The module’s operating temperature range from -25°C to +60°C further expands its usability across different climates and conditions.

    To ensure seamless integration, the Allen-Bradley 1769SC-IT6I includes RS-485 Modbus RTU communication protocol, facilitating efficient data exchange with other system components. This feature simplifies the setup process and enhances overall system efficiency.
